PINPOINTER PROBES

The Vibra-Probe 570 Pinpointer Metal Detector is a miniature version of a primary detector. It communicates through vibration, incorporates Pulse Induction (PI) technology, is waterproof to a depth of 30 feet and comes with the belt mountable holster.

Vibra-Probe 570 is fully automatic. The self calibrating microprocessor controlled circuitry requires no adjustments and utilizes automatic on and off. The modern electronics and simple to use design makes locating elusive targets easy in any environment including grass, mud, dirt, sand, black sand, or even in fresh or salt water.
Communicates with vibration
Unit signals with pulses of vibration when a target is located. It replaces the need for buzzers that can be difficult to hear, especially when wearing headphones from a primary detector.

Pulse Induction (PI)
This technology allows hunting at the beach in salt water or in any type of soil, including black sand.

Detection depth stability
New advanced circuitry maintains the unit’s detection distance throughout the life of the battery.

True target direction
The Vibra-Probe 570 detects at the tip only, not along the shaft, enabling precision target pinpointing.

Target distancing
The pulses of vibration will continue to increase in quantity as the probe tip gets closer to the target.

Automatic tuning
The state of the art microprocessor controlled design requires no adjustments of any kind.

Automatic On/Off
No push button switches. The Vibra-Probe 570 automatically turns on when pointed upward and automatically turns off one minute after last pulse.

Waterproof
Unique sealed design allows the Vibra-Probe to be used in the rain, mud, or under water to a depth of 30 feet.

Low battery indicator
Built in low battery sensor alerts you when the battery is low and needs replacing.

Easy battery installation
The standard nine-volt battery is quickly changed without tools. Simply rotate the rear knob and pull out the compression seal to access the battery compartment.

Solid construction
The Vibra-Probe’s rugged sealed construction and stainless steel hardware are built to last.

Holster
Includes belt mountable holster for easy carrying.

Vibra-Probe 570 Specifications
Detection Type
Search Mode
Overall length
Weight
Power
Warranty
Battery

Pulse Induction
All metal
14 inches
0.5 lbs
Standard 9V battery
1 year
Included
Made in USA

Field tests coming in very positive for the TREASURE MATE. Designed to find small gold nuggets, coins and relics. Makes pinpointing easy and it is getting excellent depth in mineralized ground conditions. The TREASURE MATE comes with a holster, treasure pouch and two free issues of the International California Mining Journal.

FREQUENCY: 16.5khz
COIL: 3/8" coax
SIGNAL: (1)LED and Speaker (2) LED and Vibrator
SETTINGS: Ground Balance and Tuning Controls
BATTERY: 9 Volt
BATTERY LIFE: 30~50 Hours
WEIGHT: 6 Ounces
TEMPERATURE RANGE: 30~100 Degrees F
HUMIDITY: 0~70%
MODE: All Metal, Variable Range Tunning

LIMITED LIFETIME WARRANTY

* The vibrator motor and speaker come under the limited warranty. These two parts have a limit to their life and a small charge of $9.95 will cover their replacement. All other repairs will be covered by Tesoro Electronics, Inc. and Treasure West.
* This product is warranted by Tesoro Electronics, Inc. and Treasure West to be free of defects for the life of the original purchaser, excluding the vibrator motor and speaker.
* If repair is needed, purchaser will pay shipping to Tesoro Electronics, Inc., 715 White Spar Rd., Prescott, AZ 86303. Enclose a written explanation of the problem along with your name, address and daytime phone number. This warranty does not cover negligence on your part, battery leakage or using probe for a pry tool.
